Mega Freeze Dryer

Ships in 6-8 weeks

Sale price Price $5,950.00 Regular price $6,250.00 Unit price  per

Free Shipping on $150+ to contiguous United States.



Model features:

  • Patented smart freeze drying algorithm.
  • Fans on the shelving unit for faster freezing.
  • Zoned heating for better temperature control.
  • 5 foot long stainless steel vacuum hose.
  • Stainless steel mesh filter on the vacuum line.
  • Multiple drying methods for beginners and advanced users.
  • Motorized ball valve for oil contamination prevention.
  • RTD temperature sensors for drying assistance.
  • Industrial grade glass-to-metal seal feed-through.
  • Solid state relay for the heater. All replaceable relays.
  • Stainless steel/aluminum construction for major parts.
  • Independent vacuum valve for pressure normalization.
  • Candy mode makes freeze-drying sweets easy and quick.
  • Stainless steel drain line.
Model specifications:
  • Max Ice capacity 40lb.
  • Process up to 50lb of food in one batch.
  • Main drying time 20-40 hours for 20lb of food.
  • Spacing between shelves 2 in.
  • Include six trays as one set. Tray size 10.5 in. x 27.5 in. x 0.75 in.
  • Shelf temperature setting range -50F to 150F.
  • Freeze dryer weighs (vacuum pump excluded) 268lb.
  • Freeze dryer dimension W 25.25 in. x D 33.5 in. x H 37.5 in.
  • Mega vacuum pump weighs 62 lb.
  • Vacuum pump dimension W 6.5 in. x D 21 in. x H 9 in..
  • Oil mister filter dimension W 5 in. x D 5 in. x H 8 in.
  • Vacuum pump flow rate 10.2CFM.

Installation requirement:

  • A dedicated 110v 20 Amp circuit with a NEMA 5-20 outlet is required.

Free Accessories:

  • An oil filter, an impulse sealer, and 50 mylar bags.

Shipping:

       The freeze dryer is shipped in boxes on a pallet: a 284lb freeze dryer box of size 35"x29"x43", a 62lb vacuum pump box, and a 30lb accessory box. The pallet size 40"x26"x41". The entire shipment weighs about 400lb.

Download user manual
